Description
The BMW CSL Yellow Angel Eye DRL kit replaces the standard white DRL LED rings on F80 M3 and F82/F83 M4 with factory-specification yellow units matching the BMW M4 CSL production appearance. The kit uses OEM connector plugs — no wiring m…
Quick Answer
The BMW CSL Yellow Angel Eye DRL kit replaces the standard white DRL LED rings on F80 M3 and F82/F83 M4 with factory-specification yellow units matching the BMW M4 CSL production appearance. The kit uses OEM connector plugs — no wiring modification or coding required. Installation takes approximately 45 minutes. Fully reversible.
BMW CSL Yellow Angel Eye DRL Module Kit converts the standard white daytime running lights to the iconic CSL-style yellow. Plug-and-play LED modules for G80 M3, G82 M4, and G22/G23 4 Series. No coding required. Includes 2 or 4 modules. From $279 USD at M-TRI UPGRADE.
Still rocking the stock white angel eyes on your M3 or M4?
- Every M4 CSL on Instagram has those aggressive yellow angel eyes and your standard M3 just looks… tame in comparison?
- You looked into the CSL headlight swap and found out it costs $8,000+ for the full assembly?
- You want that DTM / CSL look without ripping apart your front end or paying a shop hundreds for coding?
- You tried aftermarket LED strips and they looked cheap and uneven — nothing like the factory CSL?
BMW CSL Yellow Angel Eye DRL Module Kit
Plug-and-play DRL module kit that replaces your stock white angel eye light source with the iconic M4 CSL golden yellow. Direct OEM-fit modules — no wiring, no coding, no headlight disassembly, no bumper removal. Install in your driveway in about 2 hours.
Available Versions
- CSL Yellow (LED Headlights) — for G80/G82/G22/G26 with standard LED headlights. 4-piece set.
- CSL Yellow (Laser Headlights) — for G80/G82/G22 with laser headlight option. 11-pin connector. 4-piece set.
- RGB Multi-Color (LED Headlights) — app-controlled unlimited colors via Bluetooth. Static, breathing, strobe modes.
- RGB Multi-Color (Laser Headlights) — same as above, for laser-equipped vehicles.
What Is in the Box
- 4x DRL LED modules (2 per headlight — inner and outer ring)
- Pre-wired connectors — direct plug-in to factory harness
- Installation guide with photos
- RGB version: Bluetooth control module + smartphone app
Installation
- Open the headlight access covers from the engine bay (no bumper removal)
- Disconnect the factory white DRL module (twist-lock connector)
- Plug in the new yellow/RGB module in the same connector
- Repeat for all 4 positions (inner + outer on each headlight)
- Close covers, done — about 2 hours total
No coding required. No error codes. The modules are direct OEM-spec replacements with matching electrical characteristics.
Specifications
| Spec | Detail |
|---|---|
| Fitment | G80 M3, G82/G83 M4, G22/G23 4 Series, G26 4 Gran Coupe (2021-2025) |
| LED version OEM part# | 63119851047, 63119851048, 63119851051, 63119851052 |
| Pieces per kit | 4 (2 inner + 2 outer, left and right) |
| Material | Aluminum alloy housing, high-power LED chips |
| Color temperature | CSL Yellow: ~2800K / RGB: full spectrum |
| Installation time | ~2 hours |
| Coding required | No |
| Error codes | None — OEM-matched electrical specs |
Compatibility
| Model | Chassis | Years | LED Version | Laser Version |
|---|---|---|---|---|
| M3 / M3 Competition | G80 | 2021-2025 | Yes | Yes |
| M4 / M4 Competition | G82 / G83 | 2021-2025 | Yes | Yes |
| 430i / 430ix | G22 / G23 | 2021-2025 | Yes | N/A |
| M440i / M440ix | G22 / G23 | 2021-2025 | Yes | Yes (if equipped) |
| 4 Series Gran Coupe | G26 | 2022-2025 | Yes | N/A |
Important: You must select the correct version (LED or Laser) for your headlight type. Check if your headlights have the laser option — laser-equipped headlights have a blue accent line inside the headlight housing.
Frequently Asked Questions
How do I know if I have LED or laser headlights?
Laser headlights have a small blue “X” or blue accent line visible inside the headlight housing. If you do not see any blue markings, you have standard LED headlights. You can also check your vehicle order (VO) for option code S5AZ (Laser Light).
Will this cause any dashboard warning lights?
No. The modules match the factory electrical specifications exactly, so the car does not detect any change. No error codes, no warnings.
Can I switch back to white?
Yes. The original white modules can be reinstalled at any time. The swap takes about 30 minutes once you know the process.
Does the RGB version work while driving?
The RGB controller allows color changes while stationary. For road use, set it to a static yellow or white color. Flashing/strobing modes are for show use only — check your local regulations on DRL colors.
